Last Updated: August 3rd, 2015

InterShelter Dome Flooring & Anchoring Options KI4U, Inc. 212 Oil Patch Lane Gonzales, TX 78629 (830) 672-8734 shane@ki4u.com The dome does not come with a floor, you have to provide a pad or other flooring. Or, you can acquire one of the following two options provided by InterShelter. Both would also incur an additional freight charge which will naturally vary. Anchoring Dome suggested options are down below the flooring options. The first, GFS ReadyRoll, is favored 10 to 1 over the second, more expensive REGAL version. Ground Floor System's ReadyRoll/TFS portable flooring system This tough 1/2" thick hinged roll up mat is currently used by the military overseas, specifically designed for rapid deployment use. Specs for it can be seen here at www.groundfloorsystems.com It comes in 4 sections, with seam connectors of same material, pre-cut to make perfect circle for the 20' dome or 3 sections for the 14' dome. You can roll/lay it down first, before erecting dome or roll it out inside afterwards. Very fast, either way. Two standard colors, black or grey, custom colors on request at additional cost. Weighs 250 lbs, ships out of Virgina. First photo is GFS ReadyRoll inside the small 14' dome and second photo is the flooring for a 20' dome. The second flooring option, REGAL Instant foundation and floor system, is almost twice as expensive, but it is very robust with thick fiberglass top & bottom and 2" of polyurethane insulation sandwiched in. It'll all fit into a pick-up truck bed and goes together very fast, too, providing a 4" inch raised floor and rim that dome base and flange can be screwed onto either vertically and/or horizontally. Weighs 800 lbs, ships out of Florida, an hour away from Georgia facility. Can be picked up to save $ on crating and freight. Note: This is older photo of a dome section. The current domes have a two inch horizontal flange on all their bottom sections now, so you could also screw them down vertically into the flooring flange they sit upon, too. You could even lag bolt them down through the dome flange and then through flooring flange, all the way down into a wood deck below or use concrete fasteners if sitting atop concrete footing or pad, etc. Email shane@ki4u.com to be sent detials & prices about the domes, flooring and other options. Anchoring Options The 1,100 lb dome, even simply laying on flat ground, where wind can't get under it, is not likely to budge even in high winds because of its shape, but anchoring would be prudent. The dome has a 2" horizontal flange on all of it's lower base sections to which it can be screwed down to wood platform or footings or directly into circular concrete footings or any pad when drilled and using concrete fasteners. Here's also a DIY raised and insulated flooring... Email shane@ki4u.com to be sent detials & prices about the domes, flooring and other options. Dozens of InterShelter Dome photos, inside & out, from around the world, plus info about BIG, August Only, Discounts here! PS - For all our nuke prep products, see http://www.ki4u.com/products1.php  © www.NukAlert.com 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015. All Rights Reserved.  © www.RadShelters4U.com 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015. All Rights Reserved.  © www.RadMeters4U.com 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015. All Rights Reserved.  © www.KI4U.com 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015. All Rights Reserved.
